- Native 5600 MT/s JEDEC speed delivers high memory bandwidth without manual BIOS overclocking
- On-module PMIC improves voltage regulation and power efficiency at 1.1V
- Integrated On-Die ECC enhances internal DRAM data integrity and operational stability
- Standard 262-pin SO-DIMM profile ensures broad plug-and-play compatibility across modern laptops and mini PCs
- Relaxed JEDEC standard CL46 timings compared to low-latency enthusiast-tier memory kits
- Passive bare-PCB design lacks an integrated heatspreader, relying entirely on chassis airflow
Overview
Operating at a native JEDEC transmission rate of 5600 MT/s across dual 32-bit addressing subchannels, ADATA’s AD5S560016G-B transitions mobile and small-form-factor systems to DDR5 architecture. The module shifts primary voltage regulation from the host motherboard directly onto the PCB via an onboard Power Management IC (PMIC). Operating at a nominal 1.1V supply voltage, the PMIC optimizes power efficiency and signal fidelity, while integrated On-Die ECC (ODECC) mitigates internal memory array bit-flips prior to data transmission.
Constructed on a standard 262-pin SO-DIMM printed circuit board, the module utilizes high-density surface-mount DRAM packages configured in a single-rank topology. The unshielded, low-profile layout strictly satisfies JEDEC clearance specifications, ensuring effortless mechanical clearance inside constrained laptop bays and compact mini PC enclosures. Thermal dissipation is completely passive and governed by host chassis airflow. Operating within its rated 0°C to 85°C thermal envelope, the module draws modest active power at 1.1V, though sustained multi-core read/write workloads in slim ultrabooks with limited ventilation will cause thermal soak around the unshielded PMIC.
Programmed with standard JEDEC SPD timings of CL46-45-45, the module prioritizes out-of-the-box compatibility over aggressive enthusiast tuning. System firmware across contemporary Intel Core and AMD Ryzen mobile platforms detects the 5600 MT/s strap immediately without requiring manual timing intervention or voltage modifications. For mobile workstations, gaming laptops, and edge devices requiring straightforward RAM expansion, the module eliminates memory training instability while providing reliable platform throughput.
Technical Specifications
| Brand | ADATA |
| Model | AD5S560016G-B |
| Memory Type | DDR5 SDRAM |
| Form Factor | 262-Pin SO-DIMM |
| Capacity | 16 GB |
| Speed | 5600 MT/s (PC5-44800) |
| CAS Latency | CL46 (46-45-45) |
| Operating Voltage | 1.1V |
| Module Rank | 1Rx8 (Single Rank) |
| Error Correction | On-Die ECC (ODECC) |
| Power Management | Integrated On-Module PMIC |
| Operating Temperature | 32°F to 185°F (0°C to 85°C) |
| Dimensions | 2.74 x 1.18 x 0.15 in (69.6 x 30.0 x 3.8 mm) |
Recommended Alternatives in Memory (RAM)
At a Glance
How reliable is the ADATA 16GB 5600MHz DDR5 SO-DIMM AD5S560016G-B Review: Native 5600 MT/s DDR5 Efficiency according to Mizex audits?
An ideal plug-and-play upgrade for users seeking reliable JEDEC-standard 5600 MT/s DDR5 speeds and stable power delivery in laptops or mini PCs without configuration overhead.
What are the known quirks or drawbacks of the ADATA 16GB 5600MHz DDR5 SO-DIMM AD5S560016G-B Review: Native 5600 MT/s DDR5 Efficiency?
Our reliability audit identified the following documented caveats:
- Relaxed JEDEC standard CL46 timings compared to low-latency enthusiast-tier memory kits
- Passive bare-PCB design lacks an integrated heatspreader, relying entirely on chassis airflow
What are the key engineering highlights of the ADATA 16GB 5600MHz DDR5 SO-DIMM AD5S560016G-B Review: Native 5600 MT/s DDR5 Efficiency?
The top strengths recorded in our evaluation include:
- Native 5600 MT/s JEDEC speed delivers high memory bandwidth without manual BIOS overclocking
- On-module PMIC improves voltage regulation and power efficiency at 1.1V
- Integrated On-Die ECC enhances internal DRAM data integrity and operational stability
- Standard 262-pin SO-DIMM profile ensures broad plug-and-play compatibility across modern laptops and mini PCs
