- High-gain 5 × 8dBi omnidirectional antennas provide broad perimeter wireless coverage
- Rugged IP67-rated enclosure with weather-sealed cable gland protects against moisture and dust ingress
- Standard IEEE 802.3af/at 48V PoE support simplifies outdoor single-cable deployment
- Single 1 Gbps Ethernet port creates a physical throughput bottleneck against theoretical 2402 Mbps 5 GHz Wi-Fi 6 bandwidth
- Firmware maintenance lacks an automated cloud distribution channel, requiring manual vendor inquiries for patches
Overview
Engineered for exposed perimeter installations and expansive acreage coverage, the Adalov AX3000 packages its radio platform within an IP67-rated weatherproof polymer cylinder secured by weather-sealed O-rings and a compression-threaded RJ-45 cable gland. The exterior housing mounts five detachable 8dBi omnidirectional fiberglass antennas designed to project dual-band Wi-Fi 6 signals across outdoor yards, farms, and detached outbuildings. Structural rigidity is reinforced by a heavy-duty pole and wall mounting assembly fabricated from corrosion-resistant metal, ensuring the unit withstands wind shear and prolonged UV exposure in harsh climates.
Internally, the access point is driven by MediaTek’s Filogic 820 platform, integrating an MT7981BA dual-core network processor paired with an MT7976DN RF front-end module, 256MB of DDR3 system memory, and 16MB of SPI NOR flash storage. While the radio subsystem theoretically supports combined wireless throughput up to 3000 Mbps—delivering 574 Mbps over the 2.4 GHz band and 2402 Mbps over the 5 GHz band with 160 MHz channel width—the physical backhaul is constrained by a single 1 Gbps Gigabit Ethernet port. Thermal dissipation relies entirely on passive internal aluminum heat spreaders that route heat away from the silicon into the sealed casing’s internal cavity, maintaining reliable operational temperatures without active cooling or acoustic emissions.
Practical operation reveals a competent standalone networking device governed by a localized web interface offering standard AP, Router, Repeater, and WISP operational modes. Power delivery is handled cleanly via standard IEEE 802.3af/at 48V Power over Ethernet or the supplied passive PoE injector, eliminating the need for dedicated high-voltage outdoor wiring. However, ongoing software support reflects its white-label OEM lineage: firmware updates are not distributed through an automated cloud pipeline and typically require manual vendor requests, presenting a minor operational caveat for long-term security patching in unmanaged deployments.
Technical Specifications
| Brand | Adalov |
| Model | AX3000 Outdoor WiFi 6 Access Point |
| Wireless Standard | Wi-Fi 6 (IEEE 802.11ax/ac/n/g/b/a) |
| Wireless Speed Rating | AX3000 (2402 Mbps at 5 GHz + 574 Mbps at 2.4 GHz) |
| Processor | MediaTek MT7981BA (Filogic 820) |
| RF Chipset | MediaTek MT7976DN |
| System Memory | 256 MB DDR3 |
| Flash Storage | 16 MB SPI NOR |
| Antenna Configuration | 5 × 8 dBi External Omnidirectional Antennas |
| Ethernet Interface | 1 × 10/100/1000 Mbps RJ-45 Gigabit Port |
| Power Delivery | IEEE 802.3af/at PoE / 48V Passive PoE |
| Ingress Protection Rating | IP67 Weatherproof |
| Operating Modes | Access Point, Router, Repeater, WISP |
| Dimensions | 17.0 × 12.8 × 3.4 in (432 × 325 × 86 mm) |
| Weight | 4.85 lbs (2.20 kg) |
| Mounting Options | Pole Mount / Wall Mount |
Recommended Alternatives in Networking & Routers
At a Glance
How reliable is the Adalov AX3000 Outdoor WiFi 6 Access Point Review: Weatherproof Perimeter Coverage With Bandwidth Bottlenecks according to Mizex audits?
An effective, cost-conscious solution for blanketing large acreage in Wi-Fi 6, provided your deployment does not require multi-gigabit backhaul or automated enterprise controller management.
What are the known quirks or drawbacks of the Adalov AX3000 Outdoor WiFi 6 Access Point Review: Weatherproof Perimeter Coverage With Bandwidth Bottlenecks?
Our reliability audit identified the following documented caveats:
- Single 1 Gbps Ethernet port creates a physical throughput bottleneck against theoretical 2402 Mbps 5 GHz Wi-Fi 6 bandwidth
- Firmware maintenance lacks an automated cloud distribution channel, requiring manual vendor inquiries for patches
What are the key engineering highlights of the Adalov AX3000 Outdoor WiFi 6 Access Point Review: Weatherproof Perimeter Coverage With Bandwidth Bottlenecks?
The top strengths recorded in our evaluation include:
- High-gain 5 × 8dBi omnidirectional antennas provide broad perimeter wireless coverage
- Rugged IP67-rated enclosure with weather-sealed cable gland protects against moisture and dust ingress
- Standard IEEE 802.3af/at 48V PoE support simplifies outdoor single-cable deployment
