Overview
Heat dissipation across modern high-density CPU sockets demands aggressive fluid velocity and localized airflow, an architectural requirement met here through a hybrid mechanical cooling layout. Anchored by a 1.06-inch (27 mm) aluminum radiator and a micro-channel skived copper cold plate, the assembly circulates coolant via an integrated high-speed pump rated up to 6400 RPM. Mounted directly atop the water block is an articulate 5.5-inch IPS display panel operating at 960 x 540 resolution, engineered with 360-degree rotation and up to 157 degrees of tilt to ensure visibility across diverse chassis orientations. To mitigate the dead airflow zones common to closed-loop liquid coolers, the pump housing embeds a 2.36-inch (60 mm) auxiliary fan operating at up to 2500 RPM, channeling air downward across motherboard voltage regulator modules and surrounding power circuitry.
Thermal transfer across the radiator stack relies on the TL-UC36 unified fan assembly, which consolidates three 120 mm fan impellers into a single rigid 14.17 x 4.72 x 0.98 in (360 x 120 x 25 mm) structural frame. This unibody construction eliminates inter-fan frame gaps, preventing air pressure bleed-off while drastically simplifying cable routing via daisy-chained 4-pin PWM and 3-pin 5V addressable RGB connectors. Spinning up to 2400 RPM on S-FDB V2 fluid dynamic bearings, each fan section generates up to 71.5 CFM of airflow against 2.69 mm H2O of static pressure. While cooling headroom is formidable under heavy thermal loads, acoustic output reaches a sharp 34.59 dBA peak at maximum duty cycles. Unrestricted pump operation at 6400 RPM similarly produces audible high-frequency mechanical hum, necessitating manual BIOS or controller PWM profiling between 45% and 65% to achieve a balanced acoustic footprint.
Telemetry and display customization are driven by Thermalright’s proprietary TRCC (Thermalright Control Center) software over an internal USB interface, facilitating real-time component telemetry, static imagery, and video playback alongside fan-frame digital readouts. While functional, the companion software presents noticeable firmware cadence quirks, including frequent Windows User Account Control permission prompts upon system boot and occasional telemetry polling conflicts when running alongside third-party hardware monitoring suites. Physical integration is straightforward thanks to the SS2 multi-platform mounting kit supporting both Intel LGA1851/1700 and AMD AM5/AM4 sockets, complemented by 17.72-inch (450 mm) braided sleeved rubber tubing that accommodates expansive mid- and full-tower enclosures. Backed by a 5-year manufacturer warranty, the platform delivers high-end visual telemetry and competent thermal suppression at the expense of software polish.
Technical Specifications
| Brand | Thermalright |
| Model | TR Dynamic Vision Pro 360 ARGB Black |
| Radiator Dimensions | 15.83 x 4.72 x 1.06 in (402 x 120 x 27 mm) |
| Radiator Material | Aluminum |
| Cold Plate Material | Skived Micro-Fin Copper |
| Pump Dimensions | 2.72 x 2.99 x 3.62 in (69 x 76 x 92 mm) |
| Pump Speed Max | 6400 RPM ±10% |
| Vrm Fan Size | 2.36 in (60 mm) |
| Vrm Fan Speed Max | 2500 RPM |
| Fan Model | Thermalright TL-UC36 Unified Fan Assembly |
| Fan Dimensions | 14.17 x 4.72 x 0.98 in (360 x 120 x 25 mm) |
| Fan Speed Max | 2400 RPM ±10% |
| Fan Airflow Max | 71.5 CFM (per fan module) |
| Fan Static Pressure Max | 2.69 mm H2O |
| Fan Noise Max | 34.59 dBA |
| Fan Bearing Type | S-FDB V2 (Fluid Dynamic Bearing) |
| Display Type | 5.5-inch IPS LCD (960 x 540 resolution, 360° rotation, 157° tilt) |
| Tubing Length | 17.72 in (450 mm) |
| Tubing Material | Braided Sleeved Low-Permeation Rubber |
| Total Weight | 6.39 lbs (2.90 kg) |
| Electrical Connectors | 4-Pin PWM, 3-Pin 5V ARGB, Internal 9-Pin USB / Type-C |
| Socket Compatibility | Intel LGA1851 / LGA1700 / LGA1200 / LGA115x; AMD AM5 / AM4 |
| Warranty Period | 5 Years |
- Articulate 5.5-inch 960x540 IPS display with 360-degree rotation and 157-degree tilt
- Integrated 60 mm auxiliary fan provides dedicated active VRM and socket airflow
- Unified TL-UC36 fan assembly eliminates inter-fan frame gaps and simplifies cabling
- Generous 17.72 in (450 mm) braided tubing paired with multi-socket SS2 mounting
- TRCC companion software suffers from frequent UAC prompts and background telemetry conflicts
- High-RPM pump (6400 RPM) and 2400 RPM fans produce noticeable high-frequency noise under full load
