- Integrated 240 W internal power supply supporting 802.3at Class 4 PoE+ across all access ports
- Dual 10GbE SFP+ uplinks deliver high-speed core aggregation and stacking flexibility
- Compact 1U half-depth chassis fits seamlessly into shallow telecom racks and edge enclosures
- Dedicated out-of-band Gigabit management port and front-facing USB-C console interface
- Access interfaces are capped at 1 GbE speeds without multi-gigabit (2.5G/5G) support
- Port density is restricted to eight copper downlink interfaces, requiring clustering for larger edge deployments
Overview
Delivering enterprise switching into shallow telecom enclosures and edge deployments requires an uncompromising balance of power density and uplink bandwidth. Housing an integrated 240 W power supply within a 1U half-depth chassis, the platform eliminates unwieldy external power bricks by utilizing a standard rear IEC-60320-C14 power inlet. Its interface layout routes eight dedicated 10/100/1000BASE-T access ports alongside two 10GbE SFP+ optical cages, supplying 802.3at Class 4 PoE+ power to high-draw access points and IP surveillance hardware while securing 20 Gbps of full-duplex uplink capacity for aggregation or stacking topologies.
Constructed with a rigid steel enclosure weighing 5.00 lbs (2.27 kg), the chassis employs front-to-rear airflow to manage thermal dissipation across the internal power supply and switching silicon during sustained PoE delivery. Administrative access is decoupled from operational data paths through a dedicated out-of-band Gigabit Ethernet port and a modern USB-C console connector on the front panel. Driven by the enterprise RUCKUS FastIron operating system, the switch provides deterministic Layer 2 and Layer 3 performance, regular enterprise security patches, and seamless integration into campus network management infrastructures.
Technical Specifications
| Brand | Ruckus |
| Model | ICX8200-C08PF |
| Form Factor | 1U, half-depth rackmount |
| Total Network Interfaces | 11 ports |
| Access Ports | 8x 10/100/1000BASE-T RJ-45 |
| PoE Standard | IEEE 802.3at Class 4 (PoE+) |
| Maximum PoE Budget | 240 W |
| Uplink Ports | 2x 10GbE SFP+ (10GBASE-X) |
| Management Interface | 1x 1000BASE-T RJ-45 (dedicated out-of-band) |
| Console Interface | 1x USB-C |
| Power Supply Input | 1x internal IEC-60320-C14 |
| Airflow Design | Front-to-rear active airflow |
| Chassis Weight | 5.00 lbs (2.27 kg) |
| Operating System | RUCKUS FastIron |
Primary Sources & Audited Citations
Recommended Alternatives in Networking & Routers
At a Glance
How reliable is the Ruckus ICX8200-C08PF Review: Compact 10G Edge Power Delivery according to Mizex audits?
Ideal for enterprise edge closets and high-throughput access point deployments requiring 10GbE aggregation and integrated high-wattage PoE+ within a compact half-depth footprint.
What are the known quirks or drawbacks of the Ruckus ICX8200-C08PF Review: Compact 10G Edge Power Delivery?
Our reliability audit identified the following documented caveats:
- Access interfaces are capped at 1 GbE speeds without multi-gigabit (2.5G/5G) support
- Port density is restricted to eight copper downlink interfaces, requiring clustering for larger edge deployments
What are the key engineering highlights of the Ruckus ICX8200-C08PF Review: Compact 10G Edge Power Delivery?
The top strengths recorded in our evaluation include:
- Integrated 240 W internal power supply supporting 802.3at Class 4 PoE+ across all access ports
- Dual 10GbE SFP+ uplinks deliver high-speed core aggregation and stacking flexibility
- Compact 1U half-depth chassis fits seamlessly into shallow telecom racks and edge enclosures
- Dedicated out-of-band Gigabit management port and front-facing USB-C console interface
