Overview
Housed within a compact 93 x 60 x 29 mm plastic chassis, the physical architecture emphasizes lightweight pocketability and straightforward ergonomics. A rounded right-hand grip accommodates the dual-AA battery compartment, providing natural one-handed handling. On the optical front, a motorized 7-element, 7-group lens assembly deploys upon power-up, delivering a versatile 4x optical focal length of 4.9mm to 19.6mm (equivalent to 27mm to 108mm on a 35mm sensor) with a maximum aperture range of F3.0 at wide angle to F6.6 at full telephoto, collapsing flush into the body when powered down.
Imaging is powered by a 1/2.3-inch CMOS sensor delivering 16.35 effective megapixels and 1080p Full HD video capture at 30 frames per second in MOV Motion JPEG format, alongside a 120fps high-speed mode at 480p resolution. Focusing duties are handled by a TTL 9-point multi-zone autofocus system with face detection and object tracking, capable of macro close-ups down to 5 cm. Because the lens lacks optical image stabilization, image stability is managed digitally in firmware. Shot framing and menu navigation rely on a fixed 2.7-inch LCD panel offering 230,000 pixels of resolution, operated via tactile physical buttons rather than touch input.
Thermal dissipation is entirely passive, radiating minimal operational heat through the polymer casing without thermal throttling during extended video recording. Power architecture centers on two standard AA alkaline batteries yielding a CIPA-rated lifespan of roughly 120 shots, which can be extended using higher-capacity rechargeable NiMH cells. Data offload and storage are handled cleanly through an SD/SDHC/SDXC card slot and a legacy Micro-USB 2.0 interface, ensuring an uncomplicated workflow for everyday snapshot capture.
Technical Specifications
| Brand | Kodak |
| Model | PIXPRO FZ45 |
| Sensor Type | CMOS |
| Sensor Size | 1/2.3-inch |
| Effective Pixels | 16.35 Megapixels |
| Total Pixels | 16.76 Megapixels |
| Focal Length | 4.9mm - 19.6mm (27mm - 108mm 35mm equivalent) |
| Optical Zoom | 4x |
| Digital Zoom | 6x (30x combined) |
| Maximum Aperture | F3.0 (Wide) - F6.6 (Tele) |
| Lens Construction | 7 elements in 7 groups |
| Focusing Range | 60 cm to infinity (Wide), 100 cm to infinity (Tele); Macro: 5 cm (Wide) |
| Autofocus System | TTL 9-point Multi-AF, Single AF, Object Tracking, Face Detection |
| Image Stabilization | Digital Image Stabilization |
| Display | 2.7-inch LCD (230,000 pixels, fixed, non-touch) |
| Iso Sensitivity | ISO 100 - 3200 |
| Max Still Resolution | 4608 x 3456 (16MP, 4:3) |
| Video Recording | 1080p at 30fps, 720p at 30fps, 480p at 30fps / 120fps |
| Video Format | MOV (Motion JPEG, Linear PCM Monaural audio) |
| Storage Media | SD / SDHC / SDXC |
| Interface | USB 2.0 (Micro 5-pin) |
| Battery Type | 2x AA Alkaline / NiMH |
| Battery Life Cipa | Approx. 120 shots (Alkaline) |
| Body Material | Plastic |
| Dimensions | 93 x 60 x 29 mm |
- Versatile 4x optical zoom lens (27–108mm equivalent) with a 16.35 MP 1/2.3-inch CMOS sensor
- Operates on widely available, easily swappable AA batteries rather than proprietary packs
- Full HD 1080p video recording at 30fps with high-speed 120fps capture at 480p
- Relies entirely on software-based digital image stabilization rather than optical stabilization
- Short CIPA-rated battery life of approximately 120 exposures when using standard alkaline AA cells
- Low-resolution 2.7-inch 230K-dot LCD display lacking touchscreen support
