Overview
The Framework Desktop represents a specialized divergence from traditional small form factor computing, anchoring its architecture around AMD’s Ryzen AI Max+ Pro 495 processor with 16 cores, 32 threads, and an integrated Radeon 8065S GPU sporting 40 RDNA 3.5 compute units. Its centerpiece engineering achievement is a massive unified memory subsystem supporting up to 192 GB of high-speed LPDDR5X-8533 at 273 GB/s bandwidth, permitting up to 160 GB of memory allocation directly as dedicated VRAM for local large language model execution and high-throughput AI workloads. While the soldered LPDDR5X configuration precludes post-purchase memory expansion and the single open-ended PCIe slot operates electrically at x4 bandwidth, the system delivers workstation-class AI capability within a standardized Mini-ITX footprint.
Enclosing the platform is an accessible, modular chassis built around open PC standards, utilizing tool-free magnetic and thumbscrew panels that facilitate straightforward component servicing and hardware maintenance. Active cooling is anchored by a pre-installed 120mm Noctua NF-A12x25 fan positioned to manage airflow throughout the compact enclosure, paired with standard FlexATX power supply compatibility. Because comprehensive retail thermal dissipation and decibel load metrics remain pending final retail lab teardown verification, empirical operating limits are subject to retail validation, though native support for both Fedora Linux and Windows 11 provides a reliable, flexible environment for workstation deployment.
Technical Specifications
| Form Factor | Mini-ITX Small Form Factor (SFF) |
| Processor | AMD Ryzen AI Max+ Pro 495 (16 cores, 32 threads, up to 5.2 GHz boost) |
| Graphics | Integrated AMD Radeon 8065S (40 RDNA 3.5 Compute Units) |
| Npu Performance | 55 TOPS (131 TOPS total system AI compute) |
| Memory Capacity | Up to 192 GB unified memory |
| Memory Type | LPDDR5X-8533 |
| Memory Bandwidth | 273 GB/s |
| Allocatable Vram | Up to 160 GB |
| Expansion Slots | 1x PCIe x4 (open-ended physical slot) |
| Cooling | Pre-installed Noctua NF-A12x25 fan |
| Power Supply Compatibility | Standard FlexATX PSU |
| Chassis Features | Tool-free magnetic and thumbscrew panels, modular open PC standards |
| Supported Os | Fedora Linux, Windows 11 |
| Configurations | DIY Edition or Pre-built |
- Massive unified memory pool of up to 192 GB LPDDR5X-8533 with 273 GB/s bandwidth for local LLM workloads
- Up to 160 GB of unified system memory can be allocated directly to the integrated Radeon 8065S GPU
- Modular Mini-ITX chassis featuring tool-free magnetic and thumbscrew access with standard FlexATX PSU support
- Pre-installed premium Noctua NF-A12x25 fan for efficient SFF cooling
- PCIe add-in slot is electrically constrained to x4 bandwidth
- LPDDR5X memory is soldered to the board, preventing modular memory upgrades
