Side-by-Side Comparison
GEEKOM IT13 Max vs BOSGAME E5
Standardized 5-pillar engineering audit, thermal telemetry, verified longevity metrics, and complete technical specification diff.
▲ DOCUMENTED QUIRKS
Composite Score:
4.0
/ 5.0
High-density Meteor Lake mini PC delivering top-tier networking and expansive multi-display I/O, balanced against soldered memory and an audible load acoustic profile.
▲ DOCUMENTED QUIRKS
Composite Score:
4.0
/ 5.0
A versatile dual-LAN mini PC pairing modular DDR4 and M.2 expandability with mature Zen 2 silicon for budget-conscious homelabs.
⚖️
Mizex Comparative Audit Verdict
Both the GEEKOM IT13 Max and BOSGAME E5 share an identical composite score of 4.0. Choice between them depends primarily on specific port requirements, physical dimensions, or pricing.
5-Pillar Engineering Telemetry
Detailed comparison across standardized normalized 1.0 – 5.0 engineering pillars.
GEEKOM IT13 Max
BOSGAME E5
Engineering & Architecture
(30%)
Winner: GEEKOM IT13 Max (+0.5)
4.3
3.8
Build Quality & Materials
(20%)
Winner: GEEKOM IT13 Max (+0.1)
4.1
4.0
Thermal, Power & Acoustics
(20%)
Winner: BOSGAME E5 (+0.4)
3.6
4.0
Real-World Reliability
(20%)
Winner: GEEKOM IT13 Max (+0.1)
4.2
4.1
Buyer Value & Upgrades
(10%)
Winner: BOSGAME E5 (+0.5)
3.8
4.3
GEEKOM IT13 Max: Strengths & Caveats
✔ Advantages
- High compute throughput via 16-core Intel Core Ultra 9 185H processor and Arc graphics
- Dual 2.5Gbps Intel Ethernet ports paired with cutting-edge Intel Wi-Fi 7 wireless
- Expansive I/O suite featuring dual 40Gbps USB4 ports and quad display capability
- Straightforward maintenance with clean 4-screw access and no tethered antenna cables
✖ Documented Caveats
- Audible acoustic profile under heavy load with no custom fan curve options in BIOS
- Soldered 24GB LPDDR5 memory eliminates post-purchase RAM upgrades
- Pre-installed Kingston NV3 QLC SSD throttles during intensive sustained write workloads
BOSGAME E5: Strengths & Caveats
✔ Advantages
- Dual Ethernet LAN ports accommodate soft routing, firewall appliances, and homelab configurations
- Triple 4K@60Hz display support across HDMI 2.0, DisplayPort, and USB Type-C
- User-accessible expansion via modular DDR4 SO-DIMM slots and M.2 SSD storage
✖ Documented Caveats
- Utilizes older-generation AMD Zen 2 processor architecture
- Wireless connectivity is restricted to legacy Wi-Fi 5 and Bluetooth 5.0
Technical Specification Comparison
Side-by-side spec alignment. Rows highlighted with subtle shading denote differing specifications.
| Specification | GEEKOM IT13 Max | BOSGAME E5 |
|---|---|---|
| Brand DIFF | GEEKOM | BOSGAME |
| Model DIFF | GEEKOM IT13 Max | E5 |
| Processor DIFF | Intel Core Ultra 9 185H (16 cores: 6P + 8E + 2LPE, 22 threads, up to 5.1 GHz, 24MB cache) | AMD Ryzen 3 5300U (4 cores, 8 threads, up to 3.8 GHz, Zen 2) |
| Graphics DIFF | Intel Arc Graphics (8 Xe-cores, up to 2450 MHz) | AMD Radeon Graphics (Vega 6) |
| Neural Processing Unit DIFF | Intel AI Boost (up to 11 TOPS INT8, 35 TOPS platform) | — |
| Power Limits DIFF | 45W PL1, 70W PL2, 120W PL4 | — |
| System Memory DIFF | 24GB LPDDR5-5600 (soldered) | — |
| Primary Storage DIFF | 500GB Kingston NV3 (M.2 2280 PCIe 4.0 QLC NVMe SSD) | — |
| Secondary Storage Slot DIFF | M.2 2242 PCIe slot (up to 2TB) | — |
| Ethernet DIFF | Dual 2.5 Gbps RJ45 (Intel i226-V) | — |
| Wireless Connectivity DIFF | Wi-Fi 7 (Intel BE200NG), Bluetooth 5.4 | — |
| USB C Ports DIFF | 2x USB4 40Gbps (DisplayPort Alt Mode) | — |
| USB A Ports DIFF | 5x USB 3.2 Gen 2 (10Gbps) | — |
| Display Interfaces DIFF | 2x HDMI 2.0, 2x USB4 (up to 4 independent displays) | — |
| Card Reader DIFF | Full-size SD 4.0 slot | — |
| Audio Interface DIFF | 3.5mm stereo headset jack | 3.5mm combo audio jack |
| Power Input DIFF | DC barrel jack, 100W USB-C Power Delivery support | — |
| Operating System DIFF | Windows 11 Pro | — |
| Idle Power Consumption DIFF | 5 W | — |
| Memory DIFF | — | 8GB / 16GB DDR4 SO-DIMM (User-upgradable) |
| Storage DIFF | — | 256GB / 1TB M.2 SSD (User-upgradable) |
| Display Output DIFF | — | Triple 4K@60Hz (1x HDMI 2.0, 1x DisplayPort, 1x USB Type-C) |
| Wired Networking DIFF | — | Dual Ethernet LAN ports |
| Wireless Networking DIFF | — | Wi-Fi 5 (802.11ac) |
| Bluetooth DIFF | — | Bluetooth 5.0 |
| USB Ports DIFF | — | 1x USB Type-C, 4x USB Type-A |
| Operating System Support DIFF | — | Windows 11 Pro, Linux / Ubuntu |
