Side-by-Side Comparison
Fractal Design Radius 360 RGB vs Thermalright Dynamic Vision Pro 360 ARGB White
Standardized 5-pillar engineering audit, thermal telemetry, verified longevity metrics, and complete technical specification diff.
● HIGHLY RATED
Composite Score:
4.4
/ 5.0
A streamlined 360 mm closed-loop liquid cooler combining tube-routed fan cabling, a durable ceramic pump, and browser-based control that eliminates proprietary software overhead while maintaining stable thermal headroom.
● HIGHLY RATED
Composite Score:
4.4
/ 5.0
A feature-rich 360mm liquid cooler offering active VRM ventilation and a sharp 5.5-inch articulated display, delivering top-tier cooling value despite audible peak fan acoustics.
⚖️
Mizex Comparative Audit Verdict
Both the Fractal Design Radius 360 RGB and Thermalright Dynamic Vision Pro 360 ARGB White share an identical composite score of 4.4. Choice between them depends primarily on specific port requirements, physical dimensions, or pricing.
5-Pillar Engineering Telemetry
Detailed comparison across standardized normalized 1.0 – 5.0 engineering pillars.
Fractal Design Radius 360 RGB
Thermalright Dynamic Vision Pro 360 ARGB White
Engineering & Architecture
(30%)
Tie
4.4
4.4
Build Quality & Materials
(20%)
Tie
4.3
4.3
Thermal, Power & Acoustics
(20%)
Winner: Fractal Design Radius 360 RGB (+0.2)
4.3
4.1
Real-World Reliability
(20%)
Tie
4.4
4.4
Buyer Value & Upgrades
(10%)
Winner: Thermalright Dynamic Vision Pro 360 ARGB White (+0.1)
4.6
4.7
Fractal Design Radius 360 RGB: Strengths & Caveats
✔ Advantages
- Integrated tube-sleeved fan cabling eliminates sprawling wiring harnesses across the motherboard tray
- Web-based Fractal Adjust Pro utility and standard PWM/ARGB headers eliminate proprietary background software bloat
- Rotatable pump cap maintains proper logo orientation across diverse mounting positions
- High-efficiency C1100 copper cold plate and ceramic pump provide steady dissipation on high-TDP processors
✖ Documented Caveats
- Acoustic profile ramps sharply up to 31.9 dBA when fans exceed 2,000 RPM toward the 2,200 RPM limit
- Browser-based lighting and curve customization requires familiarity with UEFI PWM calibration for optimal acoustic tuning
Thermalright Dynamic Vision Pro 360 ARGB White: Strengths & Caveats
✔ Advantages
- Articulated 5.5-inch 960x540 IPS display supports 360-degree rotation and 157-degree tilt for flexible viewing angles.
- Integrated 60 mm pump housing fan delivers active downdraft airflow to cool motherboard VRMs and M.2 storage.
- Unibody TL-UC36 fan assembly reduces cable clutter while delivering up to 71.5 CFM airflow and 2.69 mm H2O static pressure.
- Exceptional cooling performance and feature set backed by a 5-year manufacturer warranty.
✖ Documented Caveats
- Acoustic output reaches 34.59 dBA at full 2400 RPM fan speed, requiring custom PWM curve configuration for quiet operation.
- Proprietary TRCC software is Windows-only with no official native Linux utility support.
Technical Specification Comparison
Side-by-side spec alignment. Rows highlighted with subtle shading denote differing specifications.
| Specification | Fractal Design Radius 360 RGB | Thermalright Dynamic Vision Pro 360 ARGB White |
|---|---|---|
| Brand DIFF | Fractal Design | Thermalright |
| Model DIFF | Radius 360 RGB | Dynamic Vision Pro 360 ARGB White |
| Radiator Dimensions DIFF | 15.51 x 4.72 x 1.06 in (394 x 120 x 27 mm) | 15.83 x 4.72 x 1.06 in (402 x 120 x 27 mm) |
| Total Dimensions (with Fans) DIFF | 15.51 x 4.72 x 2.17 in (394 x 120 x 55 mm) | — |
| Cold Plate Material DIFF | C1100 Copper | — |
| Radiator Material | Aluminum | Aluminum |
| Net Weight DIFF | 3.75 lbs (1.70 kg) | — |
| Tubing Length DIFF | 15.75 in (400 mm) | — |
| Tubing Material DIFF | Braided Sleeved EPDM Rubber | — |
| Fan Configuration DIFF | 3 x 120 mm Dynamic 3 RGB PWM | — |
| Fan Speed Range DIFF | 350 - 2,200 RPM | — |
| Pump Speed Range DIFF | 800 - 3,400 RPM | — |
| Pump Bearing Type DIFF | Ceramic Bearing | — |
| Maximum Fan Noise DIFF | 31.9 dBA | — |
| Socket Compatibility DIFF | Intel LGA 1851 / 1700 / 1200 / 115x, AMD AM5 / AM4 | Intel LGA1851/1700/1200/115X/2011/2066, AMD AM4/AM5 |
| Lighting Interface DIFF | 3-Pin 5V Addressable RGB (Gen 2) | — |
| Control Interface DIFF | Fractal Adjust Pro (Browser-based) & Motherboard PWM/ARGB | — |
| Cooling Type DIFF | — | All-in-One Liquid CPU Cooler |
| Pump Dimensions DIFF | — | 2.72 x 2.99 x 3.62 in (69 x 76 x 92 mm) |
| Pump Speed DIFF | — | 6400 RPM ±10% |
| Pump Connector DIFF | — | 4-Pin PWM |
| Base Plate DIFF | — | Copper Cold Plate with Micro-Channels |
| Display Specifications DIFF | — | 5.5-inch IPS LCD, 960 x 540 resolution, 360° rotation, 157° tilt |
| Embedded Pump Fan DIFF | — | 60 mm, up to 2500 RPM (active VRM/RAM airflow) |
| Fan Dimensions (Total Frame) DIFF | — | 14.17 x 4.72 x 0.98 in (360 x 120 x 25 mm) |
| Fan Speed DIFF | — | Up to 2400 RPM ±10% |
| Fan Airflow DIFF | — | 71.5 CFM (per fan) |
| Fan Static Pressure DIFF | — | 2.69 mm H2O |
| Fan Noise Level DIFF | — | Up to 34.59 dBA |
| Fan Bearing Type DIFF | — | S-FDB V2 Bearing |
| Lighting DIFF | — | Addressable RGB (ARGB) with dual rings and infinity mirror accents |
| Tubing DIFF | — | Braided sleeved rubber tubing |
| Software Interface DIFF | — | Thermalright Control Center (TRCC) via internal USB 2.0 header |
| Warranty DIFF | — | 5 Years |
