- Massive 3000W continuous output tailored for multi-GPU workstations and 24/7 heavy-duty operation
- Quad native 12V-2x6 connectors complemented by eight 8-pin (6+2) PCIe power cables
- High-efficiency 80 PLUS Platinum certification paired with comprehensive circuit protections
- Durable 140 mm 12-pole double ball bearing fan engineered for sustained thermal dissipation
- Substantial 7.87 in (200 mm) depth and 10.08 lbs (4.57 kg) weight require a large workstation chassis
- High-speed fan curve scales up to 3000 RPM under load, prioritizing component cooling over acoustic silence
- Full 3000W continuous delivery requires high-amperage mains circuits, capping at 2600W on standard 13A UK leads
Overview
Powering high-density artificial intelligence workstations and multi-GPU compute rigs presents demanding electrical challenges that standard desktop hardware simply cannot address. Delivering 3000W of sustained continuous power, this unit tackles extreme workstation configurations by integrating four native 12V-2×6 connections alongside eight supplemental PCIe 8-pin leads. This connector density allows specialized workstations to distribute balanced, dedicated current across multiple high-draw accelerators simultaneously without relying on precarious splitters or third-party adapters.
Accommodating this level of continuous electrical throughput demands substantial physical infrastructure. Weighing 10.08 lbs (4.57 kg) with an enclosure depth of 7.87 in (200 mm), the chassis requires generous interior clearance found exclusively in large workstation towers and server-grade frames. Inside, high-grade power conversion stages achieve 80 PLUS Platinum efficiency, minimizing wasted energy and mitigating internal heat accumulation during continuous operational cycles protected by a complete suite of over-current, over-voltage, and thermal fail-safes.
Thermal management prioritizes hardware preservation over near-silent operation, utilizing a heavy-duty 5.51 in (140 mm) double ball bearing fan with a 12-pole motor that ramps from 400 RPM up to 3000 RPM under maximum workload. While this airflow strategy guarantees stable 24/7 continuous operation under punishing power draws, the acoustic footprint is decidedly tailored for machine rooms and dedicated studio workspaces rather than quiet office settings. Prospective integrators must also verify regional infrastructure, as standard 13A UK wall outlets limit sustained capacity to 2600W, requiring dedicated higher-amperage circuits to realize the unit’s full 3000W potential.
Technical Specifications
| Brand | SilverStone |
| Model | HELA 3000Rz |
| Model Number | SST-HA3000R-PM |
| Rated Wattage | 3000W Continuous |
| Efficiency Certification | 80 PLUS Platinum |
| Compliance Standard | ATX 3.1 / PCIe 5.1 |
| Form Factor Depth | 7.87 in (200 mm) |
| Unit Weight | 10.08 lbs (4.57 kg) |
| Cooling Fan Size | 5.51 in (140 mm) |
| Fan Bearing Type | Double Ball Bearing |
| Fan Motor Type | 12-Pole |
| Fan Speed Range | 400 - 3000 RPM |
| Protection Circuits | OCP, OVP, OPP, SCP, OTP |
| 12V 2x6 Connectors | 4 Native |
| PCIe 6+2 Pin Connectors | 8 |
| EPS 4+4 Pin Connectors | 4 |
| ATX Main Connector | 20+4-Pin |
| SATA Connectors | 8 |
| Molex 4 Pin Connectors | 4 |
| Continuous Operation Rating | 24/7 |
Primary Sources & Audited Citations
Recommended Alternatives in Power Supplies (PSUs)
At a Glance
How reliable is the SilverStone HELA 3000Rz Review: Industrial Power Meets Wall Limits according to Mizex audits?
An uncompromising power solution for multi-GPU workstations, provided your chassis accommodates its 7.87 in (200 mm) depth and your facility supplies dedicated high-amperage wall power.
What are the known quirks or drawbacks of the SilverStone HELA 3000Rz Review: Industrial Power Meets Wall Limits?
Our reliability audit identified the following documented caveats:
- Substantial 7.87 in (200 mm) depth and 10.08 lbs (4.57 kg) weight require a large workstation chassis
- High-speed fan curve scales up to 3000 RPM under load, prioritizing component cooling over acoustic silence
- Full 3000W continuous delivery requires high-amperage mains circuits, capping at 2600W on standard 13A UK leads
What are the key engineering highlights of the SilverStone HELA 3000Rz Review: Industrial Power Meets Wall Limits?
The top strengths recorded in our evaluation include:
- Massive 3000W continuous output tailored for multi-GPU workstations and 24/7 heavy-duty operation
- Quad native 12V-2x6 connectors complemented by eight 8-pin (6+2) PCIe power cables
- High-efficiency 80 PLUS Platinum certification paired with comprehensive circuit protections
- Durable 140 mm 12-pole double ball bearing fan engineered for sustained thermal dissipation
