- Large 1/2-inch 48MP CMOS sensor with fast f/1.8 aperture and Phase Detection Auto Focus
- Ultra-compact 1.33 oz (37.7 g) unibody folding stand with integrated physical privacy cover
- Versatile dual-microphone array featuring four selectable acoustic directional modes
- Extremely low 2.0W power draw enabling cool passive operation
- 4K video capture is limited to 30fps (60fps requires dropping resolution to 1080p)
- Data transmission is restricted to USB 2.0 speeds
- Uncompressed YUV video feed is limited to a maximum resolution of 640x480
Overview
Collapsing down to an 0.74 in (18.8 mm) thickness and weighing a mere 1.33 oz (37.7 g), the unibody folding chassis integrates desktop positioning and physical security into a single mechanical structure. The articulating stand provides stable placement directly on laptop bezels or flat surfaces, doubling as a physical privacy barrier when flipped downward over the lens. Optical capture relies on a 1/2-inch 48 MP CMOS sensor paired with an f/1.8 aperture lens, supporting Phase Detection Auto Focus (PDAF) with a minimum focusing distance of 3.94 in (10 cm) to ensure crisp subject isolation without hunting.
Data transmission and power delivery are routed through a single USB Type-C connector operating on the USB 2.0 protocol. The interface limits video throughput to MJPEG compression for resolutions up to 4K (3840×2160) at 30fps and 1080p at 60fps, while uncompressed YUV transmission is constrained to 640×480 at 30fps. Drawing a maximum rated load of 2.0W (5V / 0.4A), the electronics operate within a 32°F to 104°F (0°C to 40°C) temperature envelope, dissipating heat passively across the compact polymer housing without the need for active ventilation or thermal throttling.
Acoustic input is managed by an intelligent dual-microphone array combining one directional and one omnidirectional capsule. This hardware configuration enables four switchable sound profiles—Directional, Dual-Directional, Smart Omni, and Pure Audio—tailoring polar pickup patterns to isolating nearby vocal frequencies or capturing wider room audio. While the sealed unibody construction precludes modular component repair and limits high-frame-rate 4K output, the combination of plug-and-play cross-platform compatibility across Windows and macOS, a standard UNC 1/4-20 mounting thread, and physical lens protection establishes a reliable capture setup for mobile and desktop environments.
Technical Specifications
| Brand | OBSBOT |
| Model | Meet Flip 4K |
| Sensor | 1/2" CMOS |
| Effective Pixels | 48 MP |
| Lens Aperture | f/1.8 |
| Maximum Resolution | 4K (3840x2160) @ 30fps |
| Supported Formats & Resolutions | MJPEG: 3840x2160 @ 30/29.97/25/24/20/15 fps, 1920x1080 @ 60/59.94/50/30/29.97/25/24/20/15 fps, 1280x720 @ 60/59.94/50/30/29.97/25/24/20/15 fps; YUV: 640x480 @ 30/25/24/20/15 fps, 640x360 @ 30/25/24/20/15 fps |
| Autofocus System | Phase Detection Auto Focus (PDAF) / Manual Focus |
| Focusing Distance | 3.94 in to infinity (10 cm to infinity) |
| Diagonal Field Of View | 79.1° (4:3), 72° (16:9) |
| Digital Zoom | 4x |
| HDR Support | Yes |
| Exposure Compensation | ±3 EV |
| ISO Range | 100 - 6400 |
| Shutter Speed | 1/12800s - 1/30s |
| White Balance Range | 2000K - 10000K |
| Microphone System | Intelligent Dual-Mic Array (1 Omnidirectional + 1 Directional) |
| Audio Modes | Directional, Dual-Directional, Smart Omni, Pure Audio |
| Host Interface | USB Type-C (USB 2.0) |
| Power Input | 5V / 0.4A (2.0W maximum load) |
| Mounting | Unibody adjustable stand, UNC 1/4-20 tripod thread |
| Dimensions (Working State) | 1.64 x 1.45 x 1.26 in (41.6 x 36.9 x 31.9 mm) |
| Dimensions (Folded / Off State) | 1.64 x 1.77 x 0.74 in (41.6 x 44.9 x 18.8 mm) |
| Weight | 1.33 oz (37.7 g) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Operating System Compatibility | Windows 10 (64-bit) or later, macOS 11 or later |
Primary Sources & Audited Citations
Recommended Alternatives in Webcams
At a Glance
How reliable is the OBSBOT Meet Flip 4K Review: Folding Optics Under Bandwidth Limits according to Mizex audits?
The OBSBOT Meet Flip 4K is an ideal ultra-portable webcam for mobile professionals needing sharp PDAF focus and integrated privacy, provided 30fps 4K streaming and USB 2.0 bus limits fit your workflow.
What are the known quirks or drawbacks of the OBSBOT Meet Flip 4K Review: Folding Optics Under Bandwidth Limits?
Our reliability audit identified the following documented caveats:
- 4K video capture is limited to 30fps (60fps requires dropping resolution to 1080p)
- Data transmission is restricted to USB 2.0 speeds
- Uncompressed YUV video feed is limited to a maximum resolution of 640x480
What are the key engineering highlights of the OBSBOT Meet Flip 4K Review: Folding Optics Under Bandwidth Limits?
The top strengths recorded in our evaluation include:
- Large 1/2-inch 48MP CMOS sensor with fast f/1.8 aperture and Phase Detection Auto Focus
- Ultra-compact 1.33 oz (37.7 g) unibody folding stand with integrated physical privacy cover
- Versatile dual-microphone array featuring four selectable acoustic directional modes
- Extremely low 2.0W power draw enabling cool passive operation
